HALO Square Series LL-CF6068 (Direct Light)
Features
- Patent Design Connection System, NO Light Leak, Easy For Installation
- High Luminous Flux, reach 100lm/W
- UGR 19, Micro prismatic Diffuser, Light Output Soft, Health for Eye
- Support 0-10V, Triac, DALI and Casambi Dimming
- Support Customize Curved Linear Shapes For Different Projects
- Precise Bend Tech, the diameter tolerance ±1.0mm
- Support Customized RAL/Pantone Finish Color
Parameter
| Code | Power | Input Voltage | CRI | CCT | System Output | Finish |
|---|---|---|---|---|---|---|
LL-CF6068-600*600mm | 38W | 100-240V | 80 | 3000K | 4512lm | Black/White/Customized |
4000K | 4560lm | Black/White/Customized | ||||
6000K | 4608lm | Black/White/Customized | ||||
LL-CF6068-600*1000mm | 55W | 100-240V | 80 | 3000K | 6016lm | Black/White/Customized |
4000K | 6080lm | Black/White/Customized | ||||
6000K | 6144lm | Black/White/Customized | ||||
LL-CF6068-1000*1000mm | 75W | 100-240V | 80 | 3000K | 7520lm | Black/White/Customized |
4000K | 7600lm | Black/White/Customized | ||||
6000K | 7680lm | Black/White/Customized | ||||
LL-CF6068-600*1200mm | 94W | 100-240V | 80 | 3000K | 6768lm | Black/White/Customized |
4000K | 6840lm | Black/White/Customized | ||||
6000K | 6912lm | Black/White/Customized | ||||
LL-CF6068-1200*1200mm | 113W | 100-240V | 80 | 3000K | 9024lm | Black/White/Customized |
4000K | 9120lm | Black/White/Customized | ||||
6000K | 9216lm | Black/White/Customized | ||||
LL-CF6068-1200*2400mm | 151W | 100-240V | 80 | 3000K | 13536lm | Black/White/Customized |
4000K | 13680lm | Black/White/Customized | ||||
6000K | 13824lm | Black/White/Customized |
