ERP class A
ERP class A maximum energy savings.
5050 LED application
Professional high light efficiency high power 5050 LED.
UGR < 22
Professional anti-glare design, UGR<22 optional.
DIY FIELD-Install
60°, 90°, 110° optional.
6KV surge protection
Specially designed driver with 6KV surge protection.
Classic UFO shape
Concise industry design.
| Series | Power | Voltage | DIM | Lumens | CRI | CCT | Beam | Finish | Accessory |
|---|---|---|---|---|---|---|---|---|---|
| LL-BT-RT | 80W 100W 120W 150W 200W | 120-277V ⁽¹⁾ 220-240V | ON–OFF ⁽²⁾ 0–10V DALI 2 | 14,800lm 18,500lm 22,200lm 27,750lm 37,000lm | Ra80 | 2700K 3000K 3500K 4000K 5000K 5700K 6500K | 60° 90° 110° | Black White ⁽³⁾ Grey | PR ⁽⁴⁾ AR MWS PIR EM 3-PIN |
| Nominal wattage | 80W | 100W | 120W | 150W | 200W | |
|---|---|---|---|---|---|---|
Nominal voltage & frequency | AC120-277V 50/60Hz | |||||
Inrush current & time TH50 | 100A&200uS | 80A&300uS | 80A&300uS | 100A&300uS | 100A&300uS | |
Power factor λ | >0.95 | |||||
Total harmonic distortion | <15 % | |||||
Protection class | CLASS I | |||||
Dimmable | YES | |||||
