CHALLENGER LINEAR HIGHBAY - CH 80-200W 185LM/W 14800-37000LM
LL-CH 80W
LL-CH 100W
LL-CH 120W
LL-CH 160W
LL-CH 200W
ORDER COMBO
| Series | Power | Voltage | DIM | Lumens | CRI | CCT Beam Finish | Accessory |
|---|---|---|---|---|---|---|---|
LL-BT-CH | 80W 100W 120W 160W 200W |
120-277V | 0-10V DALI 2.0 DALI D4I | 14,800lm 18,500lm 22,200lm 29,600lm 37,000lm | Ra80 | 4000K 60° Black [1] 5000K 90° White 110° Grey 45*100° | MWS [2] PIR SR EM |
APPLICATION
ELECTRICAL DATA
| Nominal wattage | 80W | 100W | 120W | 160W | 200W |
|---|---|---|---|---|---|
Nominal voltage & frequency | AC120-277V 50/60Hz | AC120-277V 50/60Hz | AC120-277V 50/60Hz | AC120-277V 50/60Hz | AC120-277V 50/60Hz |
Inrush current & time TH50 | 60A&300uS | 60A&300uS | 60A&300uS | 80A&300uS | 80A&300uS |
Power factor λ | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 |
Total harmonic distortion | <15 % | <15 % | <15 % | <15 % | <15 % |
Protection class | CLASS I | CLASS I | CLASS I | CLASS I | CLASS I |
Dimmable | Optional | Optional | Optional | Optional | Optional |
