Industrial Hazardous Lighting Industrial Hazardous

Explosion Proof Flood Light LL-EXFL-L

Application scenario

This product has good explosion-proof function, suitable for various inflammable and explosive places, mainly used in railway, electric power, metallurgy, petroleum, petrochemical, chemical, steel, aviation, ship and each Efficient lighting in factories, stations, large facilities, venues and other places.

Product Features

• The lamp body is made of aluminum alloy by die casting. The surface of the lamp is sprayed with high voltage electrostatic. The exposed fastener is stainless steel with high anti-corrosive performance. The whole lamp has excellent anti-corrosive performance.

• High-strength transparent cover, high light transmission, impact resistance, unique anti-glare design, with optical reflector cup, high reflection efficiency.

• The explosion-proof structure designed in accordance with the national explosion-proof standard GB3836 has reliable explosion proof performance, long life, special constant current power supply, low power consumption, constant output power meter, high temperature and aging resistant silica gel sealing ring, and high protection grade.

• Adopt the international first-line brand light source chip, unidirectional luminescence, no side light, high light utilization rate, high light efficiency, high display finger, with open circuit, short circuit, overheat protection function, ensure the reliable and continuous operation of light source, wide voltage input, constant light flux output, instantaneous start-up.

• Unique heat dissipation structure design, excellent and reliable heat dissipation performance, ensure the long life and reliable use of lamps. • Cable wiring, fast and convenient.

Dimensions

Product Parameters

ItemSymbolDescriptionUnit
Rated VoltageVOLTAC220V
PowerP80-120W
Protection LevelIPIP66IP
Lighting Angleθ45/60/90°
LED Qty/120PCS
Base specifications/CREE3030
Anti-corrosion grade/WF2
Explosion proof grade/ExDEmd CT6
Light efficiencyη120Lm/W
Frequencyf50/60Hz
Power FactorPF>0.95PF
Operating TemperatureTOPR-20~40°C
Storage TemperatureTOPR-20~40°C
Light Source/led
Correlate Color TemperatureCCT3000-6500K
Color Rendering IndexCRI≥70RA
LED'S Operating LifeLIFE100000Hours
Start-up timeT≤0.2S
Executive standard/GB3836.1、GB3836.2
Weight/4.8KG
Size/299×186×174mm
