Solar Street Light 60W 80W 100W
LL-FLC50W
LL-FLC100W
LL-FLC150W
LL-FLC200W
LL-SE02
FLC-LED
FLC50W-LL
FLC100W-LL
Model LL-FLC50W LL-FLC100W LL-FLC150W LL-FLC200W Power(W) 30-40-50W 60-80-100W 100-120-150W 120-150-200W Input voltage Normal Voltage=100-277VAC, High Voltage=200-480VAC, please read *Note-1 before choosing Driver Efficiency ≥96% ≥96% ≥96% ≥96% Control Option Driver includes wiring for 0-10V dimming systems. Dim as low as 10%. Emergency Time 180 Minutes Operating Temperature -40°C to 50°C (-40 °F to 122 °F) Storage Temperature -40°C to 80°C (-40 °F to 176 °F) Surge Protection 10KV SPD in standard Efficacy (lm/W)±5% @2835 150lm/W 150lm/W 150lm/W 150lm/W Luminous flux(lm)±5%@CRI 70Ra, 4000K 4500-7500lm 9000-15000lm 15000-22500lm 18000-30000lm Efficacy (lm/W)±5% @5050 170lm/W 170lm/W 170lm/W 170lm/W Luminous flux(lm)±5%@CRI 70Ra, 4000K 5100-8500lm 10200-17000lm 17000-25500lm 20400-34000lm Efficacy (lm/W)±5% @A5050 195-192-190lm/W 190-188-185lm/W 190-185-182lm/W 190-185-182lm/W Luminous flux(lm)±5%@CRI 70Ra, 4000K 5850-9500lm 11400-18500lm 19000-27300lm 22800-36400lm
Technical Specifications
| Wattage | 30W |
| Color Temp | 3000K~5000K |
| CRI | 5 years limited warranty in standard, 10 years opt |
| IP Rating | 10KV SPD in standard |
| Input Voltage | Normal Voltage=100-277VAC, High Voltage=200-480VAC, please read *Note-1 before choosing |
| Beam Angle | 15°/30°/45°/60°/90°/120°/T2(60*150°)/T3(70*150°)/T |
| Color Temperature | 3000K~5000K |
| Efficacy | 195-192-190lm/W / 190-188-185lm/W / 190-185-182lm/W |
| Material | Heavy-duty die-cast aluminum (EN AC-46100) |
| Power / Wattage | 30W |
| Voltage | Normal Voltage=100-277VAC, High Voltage=200-480VAC, please read *Note-1 before choosing |
